trash compression trash can waste collector compactor model garbage trucks
Product Parameters
Product Images
Product Details
| Chassis Description | |
| Cab | Single row non-longhead cab can turn over |
| Color | Optional |
| Allowable person in cab | 2/3 |
| Wheel base (mm) | 4500 |
| Number of axles | 2 |
| Front axle | 5000 |
| Rear axle | 10000 |
| Traction system | 4×2 |
| Tire specification | 10.00-20 |
| Tire quantity | 6+1 |
| Engine Description | |
| Engine manufacture | YUCHAI Engines |
| Engine model | CY4102-C3F |
| Emission standard | Euro 3 |
| Exhaust/output | 5900ml/140kw |
| Horse power | 190hp |
| Up-parts Description | |
| Loading Circulation Time (s) | 12-30 |
| Rubbish Discharging Time(s) | <30 |
| Oil Pressure(Mpa/kg) | 19.6/200 |
| Factual loading(kg) | 5000 |
| Compressed Proportion | 1:3/1:2 |
| Power of movement | Hydraulic pump |
| Standard Equipment | Equipped with hermetic dustbin, hydraulic system and operating system Automatic compress and uninstall, sewage can be collected by the dump tank. Pressure is large, leakproofness is good, operation is convenient and security is dependable |
