Biomedical Waste Disinfection System 5

MEDICAL WASTE:A WORLDWIDE ISSUEFOR PUBLIC HEALTH & ENVIRONMENTHealth care activities protect and save lives.But what about the waste and by-products that they generate?Biomedical waste management process can be expensive and difficult to set up for health care centers.An unsafe management can cause major issues: Me

Featured Products

Health care activities protect and save lives.But what about the waste and by-products that they generate?Biomedical waste management process can be expensive and difficult to set up for health care centers.An unsafe management can cause major issues:

Biomedical Waste Sterilizer System 5
Medical waste contains
potentially harmful
microorganisms which
could infect people


The World Health Organization
(WHO) estimates that 40%
of hepatitis cases and 2,5% of HIV
cases worldwide are caused
by occupational exposure

Treatment and disposal
of healthcare waste may
release pathogens and
toxic pollutants


Biomedical Waste Sterilizer System 5
Biomedical Waste Sterilizer System 5
Medical waste treatment with microwave disinfection equipment can solve the problem of medical waste infecting humans and polluting the environment

Biomedical Waste Sterilizer System 5

Microwave disinfection technology principle

Microwave antivirus is the result of microwave thermal effect and biological effect, which can make microwave energy and bacteria directly interact, rapid sterilization.

1.The thermal effect of microwave energy:Under certain intensity microwave field, the bacteria will be due to the absorption of polarized molecules can increase the temperature of microwave, so that the protein deformation, loss of biological activity.The thermal effect of microwave mainly plays the role of rapid temperature sterilization.

2.Non-thermal effects of microwave energy:High frequency electric fields change the polarized molecular structure, resulting in the loss of vitality or death of proteins and physiologically active substances in the microbes, and the special effects of conventional physical sterilization.

Technical characteristics

Microwave disinfection technology uses a microwave sterilization time is short, fast, penetrating ability, inside and outside the temperature uniformity, saving energy, disinfection effect of good characteristics.

In the microwave field, the cell structure is destroyed, destroying the cell inside and outside the material balance, causing cell death.

The combination of microwave and water vapor makes the disinfection effect more effective.

Microwave disinfection does not produce dioxin and malodorous gases, no waste water.

Biomedical Waste Sterilizer System 5

CE & ISO9001-2015 Certificate

Biomedical Waste Sterilizer System 5

Compare technologiesLiYing TechnologyAutoclaveAutoclave with a shedderIncinerator
(microwave process)(hot steam process)(hot steam process)(high-heat process)
Continuous processXXX
Integral shreddingXX
Unrecognisable wasteX
Volume of waste reductionX
Mass of waste reductionXX
Installation requirementsLowHighHighHigh
Complexity of the installationLowIntermediateIntermediateHigh
Possibility of installation "in situ"X
Technology approval and recognition by countries all over the worldHighIntermediateHighLow
Level of sterelizationHighIntermediateHighHigh
Level of noiseLowIntermediateIntermediateHigh
Treatment of pathological and anatomical wasteX
Investment costsIntermediateLowIntermediateHigh
Operating costsLowHighHighHigh
Maintenance costsLowHighHighHigh
Labour costsLowHighHighHigh
Impact on the environmentNoIntermediateIntermediateHigh
Treated waste recyclableXXX
No contaminated rejection (such as water, steam)XXX
No risk related to pressurized vesselXXX
Risk for workforce/personnel health (no risk of toxic contaminants released into the air or the treated waste)NoIntermediateIntermediateHigh

Biomedical Waste Sterilizer System 5

Detailed parameters
Dimensions8.3m lenght x2.9m widthx3.3m high
Treatment typePre-shredding with core-hearting microwave disinfection technology
Type of processAutomatic continuous process
Processing capacity300kg/hr
EmissionsZero emission
Energy consumption117 kw ( 20° C at 1 atm )
EffectivnessMore than 6log10 disinfection
Required floor space9m x 3m ( 6 m height )
Manpower requirementsNo specialized operator / 1 operator
Assembly and start-upOne day assembly - start-up & training with our engineers

Solution adapted to:
1.Every medical waste producers

Biomedical Waste Sterilizer System 5

2.Any type of medical waste
  • Blood and Blood Products
  • Dialysis Waste
  • Animal Tissues, Body Parts, and Carcasses
  • Human Tissues, Body Parts, and Limbs
  • Biological and Non-Hazardous Pharmaceutical
  • Needles, Syringes, and other Sharps
  • Research Waste
  • Laboratory Specimens
  • Surgery Waste
  • Pathology and Histology Samples
  • Aids and Hepatitis Waste
  • Isolation Waste
  • Cultures and Slides
  • Intravenous Bags, Blood Bags, and Associated Tubing
  • Animal Bedding
  • Packaging Materials
  • Gloves, and Gowns Associated with Waste Collection
  • Trace Chemotherapy/anti-neo plastic waste

About Us
Henan Liying Environmental Science and Technology Co., a commitment to medical waste harmless treatment technology research and development, equipment production and project investment and operation of the specialized companies, is a state-level high-tech enterprises and the National Environmental Protection Association member units. Companies in the "professional, dedicated, specifically" attitude, "harmless treatment of medical waste, for the benefit of future generations" as the core value, market-oriented, healthy and environmentally friendly, resource recycling-oriented, committed to In the medical waste treatment technology research and development, equipment production, project investment operations.
The company is located in the civil rights county high-tech development zone,  The company has a number of invention patents, utility model patents and software copyright, research and development of microwave sterilization, carbonization pyrolysis and other medical waste disposal technology in the international leading level, through the GB / TI9001 international quality management system certification, CE certification by SGS, and has won the international Trade platform designated enterprise authorization certificate, scientific and technological achievements appraisal certificate, science and technology SME certificate, China 's environmental protection industry sustainable development key promotion project certificate. Investment, construction, operation or cooperation of municipal (county) medical waste disposal center in Shandong, Qingdao, Shijiazhuang, Hebei, Lankao, Luyi, Changyuan, Jiangxi Yingtan, Guizhou Zhenfeng, Pu'an, Sands, Yunnan Tengchong and Fengqing Project experience, the successful solution to Shandong Heze, Qingdao, Liaocheng, Hunan Changde City, Jiangxi Ji'an City, Jiangsu Qidong City, Guizhou Anshun City and other medical waste emergency treatment problems. Production of equipment exported to the United States, Britain, Brazil, India, Japan, Russia and other countries.
